Natural Gas Steam Boiler

Natural Gas Steam Boiler

Natural Gas Steam Boiler
  • gas steam boiler powerRated thermal power:0.5-140t/h
  • gas steam boiler efficiencyRated thermal efficiency:85-95%
  • gas steam boiler pressurePressure:1-750psi
  • gas steam boiler fuelAvailable fuel:natural gas、LPG、propane, etc
  • Product description
  • Product advantages
  • Technical features
  • Model parameters

Product Description

Natural Gas Steam Boiler description icon

Fangkuai’s natural gas steam boiler is a type of heating system that uses natural gas as its fuel source to heat water and produce steam. The steam generated by the boiler can be used for a variety of purposes, including space heating, water heating, and industrial processes. The boiler works by burning natural gas in a combustion chamber, which heats up a series of tubes that contain water. As the water absorbs the heat, it turns into steam, which is then transported through pipes to various parts of a building or industrial facility. They are commonly used in residential, commercial, and industrial applications and can range in size from small units designed for single-family homes to large industrial-sized boilers used in manufacturing plants.

Product Advantages

Natural Gas Steam Boiler advantages icon
  • High Efficiency

    Natural gas fired steam boilers are highly efficient and can achieve efficiency ratings of up to 98%. This means that almost all of the energy in the natural gas is converted into heat.

  • Cost-effective

    Natural gas is generally less expensive than other fuels such as oil or propane, which can help to reduce operating costs for a natural gas fired steam boiler.

  • Safety & Reliability

    Natural gas is a reliable fuel source that is readily available in most areas, which helps to ensure a consistent supply of fuel for the boiler. And with built-in safety features such as automatic shut-off valves and flame sensors that help to prevent accidents.

  • Clean Burning

    Natural gas produces fewer emissions and pollutants compared to other fuels, which can help to improve air quality and reduce environmental impact.

Technical Features

Natural Gas Steam Boiler features icon
  • Full premix combustion technology

    Full premix combustion technology is a type of combustion technology used in natural gas steam boilers that combines the fuel (natural gas) and air in a precise ratio before they enter the combustion chamber. This creates a uniform and stable flame that burns with high efficiency and low emissions. The unique aspect of full premix combustion technology is that it uses a special type of burner that mixes the fuel and air thoroughly before igniting it. This is different from conventional burners, which use separate fuel and air streams that mix together in the combustion chamber.

  • Control and monitoring technology

    The control and monitoring technology of a natural gas steam boiler includes a range of sensors, controllers, and software that work together to monitor and control the various parameters of the boiler, ensuring safe and efficient operation. These sensors measure the pressure, temperature, and flow of steam and water in the boiler and send signals to the controller to adjust the firing rate of the burners or the flow rate of water to maintain the desired pressure and temperature to maintain the desired steam output. This software receives inputs from the sensors and controllers and uses algorithms to make decisions about adjusting the burner firing rate, water flow rate, or other parameters to optimize the efficiency and performance of the boiler.

Model Parameters

Natural Gas Steam Boiler parameters icon
Types Evaporation Steam pressure Steam temperature Feed water temperature Thermal efficiency Fuel Power requirement Length * Width * Height Weight Chimney
Unit t/h MPa °C °C % V/Hz mm t mm
WNS1-1.0-Y.Q 1 ≤3.82 (184)
194
(204)
20 97-100 Diesel,
heavy oil,
natural gas,
city gas
380/50 3830 * 1900 * 3010 5.6 300
WNS2-1.0-Y.Q 2 4860 * 2670 * 3290 8.2 350
WNS2-1.25-Y.Q 2 5020 * 2560 * 3250 12.1 350
WNS3-1.25-Y.Q 3 5110 * 2790 * 3490 16 450
WNS4-1.25-Y.Q 4 6110 * 2800 * 3640 11.3 450
WNS6-1.25-Y.Q 6 6950 * 2910 * 3830 16.7 550
WNS8-1.25-Y.Q 8 7530 * 3390 * 4350 21.9 550
WNS10-1.25-Y.Q 10 8300 * 3260 * 4320 25.9 700
WNS10-1.6-Y.Q 10 8300 * 3310 * 4320 28.2 700
WNS15-1.25-YQ 15 8750 * 3500 * 4430 34.9 900
WNS15-1.6-YQ 15 8750 * 3500 * 4430 39.3 900
WNS20-1.25-YQ 20 9620 * 5180 * 5270 41.9 900
